Blog

BDD Framework List

by admin | Aug 28, 2016 | 2016, Fixed | 0 comments

There are various frameworks available for Behavior-Driven Development (BDD). As an automation testing services company, we have used Cucumber, Behave, and Specflow for test automation projects.

However, we have found and listed 25 BDD frameworks
which are popular among experts.

Cucumber

Cucumber is a software tool that computer programmers use for testing other software. It runs automated acceptance tests written in a behavior-driven development (BDD) style. Cucumber is written in the Ruby programming language. Cucumber projects are available for other platforms beyond Ruby.

Link: https://cucumber.io/

Serenity BDD

Serenity BDD helps you write better, more effective automated acceptance tests, and use these acceptance tests to produce world-class test reports and living documentation

Link: Serenity BDD

SpecFlow

SpecFlow acceptance tests follow the BDD paradigm: define specifications using examples understandable to business users as well as developers and testers. SpecFlow integrates with Visual Studio, but can be also used from the command line.

Link: http://www.specflow.org/

Jasmine

Jasmine is a behavior-driven development framework for testing JavaScript code. It does not depend on any other JavaScript frameworks. It does not require a DOM. And it has a clean, obvious syntax so that you can easily write tests.

Link: http://jasmine.github.io/2.0/introduction.html

GivWenZen

GivWenZen allows a user to use the BDD Given When Then vocabulary and plain text sentences to help a team get the words right and create a ubiquitous language to describe and test a business domain.

Link: https://github.com/weswilliams/GivWenZen

easyb

easyb is a behavior driven development framework for the Java platform. By using a specification based Domain Specific Language, easyb aims to enable executable, yet readable documentation.

Link: http://easyb.org/

Concordion

Concordion is an open-source tool for automating Specification by Example. It’s used by product teams all over the world to help them deliver great software.

Link: http://concordion.org/

cola-tests

COLA Tests are different from all other BDD framework as it allows for developers to keep using any JUnit Runner without having to do any complex configuration or setup.

Link: https://github.com/bmsantos/cola-tests

Behat

Behat is an open source Behavior Driven Development framework for PHP 5.3+. What’s behavior driven development, you ask? It’s a way to develop software through a constant communication with stakeholders in form of examples; examples of how this software should help them, and you, to achieve your goals.

Link: http://docs.behat.org/en/v3.0/

Squish

Squish’s support for BDD is unique because it tightly combines and integrates the BDD approach and GUI test automation.

Link: https://www.froglogic.com/squish/gui-testing/features/index.php?id=bdd.html

Jdave

JDave is a BDD framework for Java. It is inspired by rspec and integrates JMock 2 as mocking framework and Hamcrest as matching library. It uses JUnit adapter to launch JDave specifications.

Link: https://github.com/jdave/Jdave

behave

behave is behaviour-driven development and uses tests written in a natural language style, backed up by Python code.

Link: https://pypi.org/project/behave/

Lettuce

Lettuce is a very simple BDD tool based on the Cucumber, which currently has many more features than Lettuce.
Lettuce aims the most common tasks on BDD and it focus specially on those that make BDD so fun 🙂

Link: http://lettuce.it/

Frank

Frank allows you to write structured text test/acceptance tests/requirements (using Cucumber) and have them execute against your iOS application.

Link: http://www.testingwithfrank.com/

Codeception

All Codeception tests are written in a descriptive manner. Just by looking at the test body you can get a clear understanding of what is being tested and how it is performed. Even complex tests with many assertions are written in a simple PHP DSL.

Link: http://codeception.com/docs/07-BDD

Chakram

Chakram is a REST API testing framework offering a BDD testing style and fully exploiting promises.

Link: http://dareid.github.io/chakram/

Nbehave

NBehave is a framework for behaviour-driven development (BDD). BDD is an evolution of test-driven development (TDD) and acceptance-test driven design, and it is intended to make these practices more accessible and intuitive to newcomers and experts alike.

Link: https://github.com/nbehave/NBehave/wiki/Getting%20Started

Jbehave

JBehave is a framework for Behaviour-Driven Development (BDD). BDD is an evolution of test-driven development (TDD) and acceptance-test driven design, and is intended to make these practices more accessible and intuitive to newcomers and experts alike. It shifts the vocabulary from being test-based to behaviour-based, and positions itself as a design philosophy.

Link: http://jbehave.org/

minitest

minitest provides a complete suite of testing facilities supporting TDD, BDD, mocking, and benchmarking.

Link: https://github.com/seattlerb/minitest

Hiptest

Hiptest, a realtime test management platform that supports behaviour driven development and seamlessly blends in continuous delivery processes.

Link: https://github.com/hiptest

Gauge

Gauge is an open source test automation tool that is completely hackable. Written in golang, Gauge lets you write tests in plain-speak and refactor fearlessly.

Link: https://github.com/getgauge/

LightBDD

Lightweight Behavior Driven Development test framework.

Link: https://github.com/Suremaker/LightBDD

Specter

Specter enables behavior driven development (BDD) by allowing developers to write executable specifications for their objects, before actually implementing them.

Link: http://specter.sourceforge.net/

SubSpec

SubSpec xUnit BDD Framework.

Link: https://github.com/topics/subspecs

System.Spec

System.Spec is testing tool for the C# programming language.

Link: https://github.com/alexfalkowski/System.Spec

Selenium WebDriver and Java 8

by admin | Aug 24, 2016 | 2016, Fixed | 0 comments

From Selenium 3.0, minimum Java version is 8. In this blog article, we would like to show you how to use Java 8 features like Lambda expression and Collections Stream to simplify Selenium WebDriver snippets.

Let’s start with Lambda expression.

Java lambda expressions are Java’s first step into functional programming. A Java lambda expression is thus a function which can be created without belonging to any class. A lambda expression can be passed around as if it was an object and executed on demand.

Source: Tutorials Jenkov

Let’s say you want to print all the elements from an array list without lambda expression; then you will come up with the below snippet.

List list=new ArrayList();

list.add("Selenium");
list.add("UFT");
list.add("Appium");

for(String item:list){
  System.out.println(item);
}


The same logic, we can implement a lot easier with lambda expression in Java 8.

list.forEach(item -> System.out.println(item));


Collections Stream

Collections Stream is a new feature in Java 8. A stream represents a sequence of elements and supports different kind of operations from a collection.

Let’s say you want to check whether an option is available or not in a drop-down list.

Select select=new Select(driver.findElement(By.id("drp1")));

//Validating drop-down option without For Loop
select.getOptions().stream().anyMatch(item->item.getText().equals("Option1"))


Filtering WebElements using Regular Expression

driver.get("file:///C:/sample.html");

List<WebElement> elements=driver.findElements( By.xpath("//input[@type='checkbox']"));

elements.stream()
     .filter(element->Pattern.compile("check_(\d+)_box").matcher(element.getAttribute("id")).matches())
     .forEach(element->element.click());

Getting a visible WebElement from WebElement List

driver.findElements(By.xpath("//input"))
                    .stream()
                    .filter(elemnt -> elemnt.isDisplayed())
                    .findFirst()
                    .get()
                    .sendKeys("codoid-testing company");


Very Simple, isn’t it?

Selenium ExpectedConditions With Logical Operators

by admin | Jun 29, 2016 | 2016, Fixed | 0 comments

How to check or wait until multiple web elements are visible in one webdriver ExpectedCondition? Or how to wait until at least one element is clickable in a group of web elements?

Selenium WebDriver ExpectedCondition supports logical operators which has answers for the above questions and it also helps to create robust automation test scripts. Let’s see ExpectedConditions’ logical operators with examples.

AND Operator

//Wait until both the elements are visible
wait.until(
              ExpectedConditions.and(
                   ExpectedConditions.visibilityOfAllElementsLocatedBy(By.name("Services")),
                   ExpectedConditions.visibilityOfAllElementsLocatedBy(By.name("Products"))
              )
          );


OR Operator

//Wait until at least anyone condition returns true
wait.until(
              ExpectedConditions.or(
                   ExpectedConditions.visibilityOfAllElementsLocatedBy(By.name("Services")),
                   ExpectedConditions.visibilityOfAllElementsLocatedBy(By.name("Products"))
                   ExpectedConditions.visibilityOfAllElementsLocatedBy(By.name("Contact Us"))
              )
          );


Creating a Ruby Cucumber Project

by admin | Jun 2, 2016 | 2016, Fixed | 0 comments

This is our first blog post on Ruby Cucumber automation testing and as an automation testing services company, we would like to share basic and advanced techniques of automation testing with software testing & quality assurance communities.

In this article, we will show you how to create a feature file and implementation code using RubyMine. Before following up the below steps, make sure you have already configured RubyMine

Step1-Create Empty Ruby Project

File->New Project

Step2-Create Gem file

Select project directory, right click and click New->File

Create Gem file with the following Gem details as shown below.

Note: These Gem details will be published in our next article.

source 'https://rubygems.org/'
gem 'cucumber', '1.2.1'
gem 'rspec', '2.10.0'
gem 'ffi', '1.3.1'
gem 'watir-webdriver', '0.7.0'
gem 'watir'
gem 'selenium-webdriver'
gem 'headless', '0.2.2'
gem 'titleize', '1.2.1'
gem 'json', '1.7.7'
gem 'gherkin', '<= 2.11.6'
gem 'syntax'


Step3-Directory Structure

Create sub folders as shown below

—>features

————->Project1

——————->feature

——————->pages

——————->step_definitions

————->Support

Step4-Create Shared Driver

Create SharedDriver.rb inside Support folder with the following code.

require 'rubygems'
require 'rspec'
require 'watir-webdriver'

include Selenium

#Creating Remote WebDriver
browser = Watir::Browser.new(:remote, :url => "http://SauceUsername:[email protected]:80/wd/hub",
                              :desired_capabilities => WebDriver::Remote::Capabilities.firefox)
#If you want to run it locally, use Watir::Browser.new :firefox

Before do
  @browser = browser
end


Step5-Create Feature file

Create sample.feature file inside feature folder with the below steps

Feature: Sample Feature

  Scenario: Sample Scenario
    Given I launch https://codoid.com
    And I click on Login tab
    And I enter username
    And I enter password
    When I click Login button
    Then I see Home page


Step6-Create Step Definitions

Create Step Definitions with pending steps

Given(/^I launch http://www.codoid.com$/) do
  pending
end

And(/^I click on Login tab$/) do
  pending
end

And(/^I enter username$/) do
  pending
end

And(/^I enter password$/) do
  pending
end

When(/^I click Login button$/) do
  pending
end

Then(/^I see Home page$/) do
  pending
end


Step7-Create Page Object

class LoginPage
  attr_accessor :loginTab,:txtUsername,:txtPassword,:btnLogin

  def initialize(browser)
    @browser = browser
    @loginTab    = @browser.a(:text => "Login")
    @txtUsername = @browser.text_field(:id => "userId")
    @txtPassword = @browser.text_field(:id => "password")
    @btnLogin      = @browser.element(:id => "log_in_button")
  end

  def visit
    @browser.goto "https://codoid.com"
  end

  def clickLoginTab()
    @loginTab.click
  end

  def enterUsername(username)
    @txtUsername.set username
  end

  def enterPassword(password)
    @txtPassword.set password
  end

  def clickLoginButton
    @btnLogin.click
  end

  def verifyHomePageHeader()
    @browser.element(:text => "Dashboard").wait_until_present
  end
end


Step8-Call Page Methods in Step Definitions

Given(/^I launch http://www.codoid.com$/) do
  @LoginPage = LoginPage.new(@browser)
  @LoginPage.visit
end

And(/^I click on Login tab$/) do
  @LoginPage.clickLoginTab
end

And(/^I enter username$/) do
  @LoginPage.enterUsername("xxxxxxx")
end

And(/^I enter password$/) do
  @LoginPage.enterPassword("yyyyyyy")
end

When(/^I click Login button$/) do
  @LoginPage.clickLoginButton
end

Then(/^I see Home page$/) do
  @LoginPage.verifyHomePageHeader
end


Step9-Create cucumber.yml file

Create cucumber.yml file inside project directory as shown below

default: --format html --out=Report.html


Step10-Run the feature file

Once execution is done, open the report file

You will see the report as shown below

In the subsequent articles, we will share more topics and advanced techniques. Stay tuned!
